DN 250 welding plate Flange from China manufacturer

Price:	5.0~2000.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: DN 250 class 250

Production Capacity: 1,118,000 Tons / Year

Delivery Date: 3~30days or negotiable

Material: Stainless Steel

standard: ASME B 16.5

technics: forging

Means of Transport: Ocean,Land,Air

Packing: as the expore standards pac...

Standard or Nonstandard: Standard

Brand Name: gee

surface: FF/RF

1.Corrosion resistance,
2.low density,
3.high strength
4.Excellent quality, high efficiency, good after-sales

Flange

name	carbon steel flange
Type	butt welded flange slip-on flange blind flange ring-joint flange threaded flange
size	1/2"-100" (DN15-DN2500)
Wall thickness	SCH10S-SCH160,STD,XS,XXS

Material

Carbon steel	A234 WPB ,ST37.0 , 20# etc.
Stainless steel	304,304L,316,316L,A403,A312,1.4301,1.4306,1.4401,1.4571 etc.
Alloy steel	A234WP12,A234WP11,A234WP22,A234WP5,A234WP9,A335 P11,A335P22,A335 P5 ,A335P9 etc.

Standard

ASME	ANSI B16.9 , ANSIB16.28
DIN	DIN2605, DIN2615 ,DIN2616,DIN2617,DIN2801 etc.
JIS	JIS B2311, JISB2312,JISB2313
EN	EN10253-1,EN10253-2

. Chemical requirements

	N	C	H	Fe	O	Al	V	Pd	Mo	Ni	Ti
Gr	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr 2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr 5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal
Gr 7	0.03	0.08	0.015	0.30	0.25	/	/	0.12~0.25	/	/	bal
Gr 9	0.03	0.08	0.015	0.25	0.15	2.5~3.5	2.0~3.0	/	/	/	bal
Gr12	0.03	0.08	0.015	0.30	0.25	/	/	/	0.2~0.4	0.6~0.9	bal

3. Tensilerequirements

grade	Tensile strength(min)		Yeild strength(min)		Elongation(%)
grade	ksi	MPa	ksi	MPa	Elongation(%)
1	35	240	20	138	24
2	50	345	40	275	20
5	130	895	120	828	10
7	50	345	40	275	20
9	90	620	70	438	15
12	70	438	50	345

British Standard BS 10 : 1962 - Specification for Flanges andBolting for Pipes, Valves, and Fittings. This covers plain, boss, integrallycast or forged, and welding neck type flanges, in ten tables. Although BS 10 isobsolescent, it remains in use for the dimensions of light duty, economystainless steel flanges in applications where corrosion resistance and/orhygiene, rather than high pressures and temperatures, are the primaryconsiderations. The following tables detail the applicable standard dimensionsfrom Tables D, E, F and H of BS 10.
the flow chart:

china gee pipeforged stainless steel/alloy steel /carbon steelplate Flange
